NeuroML C++ API
2.3.0
C++ API for NeuroML 2
|
Class corresponding to the ConcentrationModel_D schema type. More...
#include <NeuroML_v2.3.hxx>
type | |
Accessor and modifier functions for the type required attribute. | |
typedef ::xml_schema::simple_type | type_type |
Attribute type. | |
typedef ::xsd::cxx::tree::traits< type_type, char > | type_traits |
Attribute traits type. | |
const type_type & | type () const |
Return a read-only (constant) reference to the attribute. More... | |
static const type_type & | type_default_value () |
Return the default value for the attribute. More... | |
Constructors | |
ConcentrationModel_D (const id_type &, const ion_type &, const restingConc_type &, const decayConstant_type &, const shellThickness_type &) | |
Create an instance from the ultimate base and initializers for required elements and attributes. | |
ConcentrationModel_D (const ::xercesc::DOMElement &e, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a DOM element. More... | |
ConcentrationModel_D (const ConcentrationModel_D &x, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Copy constructor. More... | |
virtual ConcentrationModel_D * | _clone (::xml_schema::flags f=0, ::xml_schema::container *c=0) const |
Copy the instance polymorphically. More... | |
ConcentrationModel_D & | operator= (const ConcentrationModel_D &x) |
Copy assignment operator. More... | |
virtual | ~ConcentrationModel_D () |
Destructor. | |
Additional Inherited Members | |
![]() | |
typedef ::neuroml2::NmlId | ion_type |
Attribute type. | |
typedef ::xsd::cxx::tree::traits< ion_type, char > | ion_traits |
Attribute traits type. | |
typedef ::neuroml2::Nml2Quantity_concentration | restingConc_type |
Attribute type. | |
typedef ::xsd::cxx::tree::traits< restingConc_type, char > | restingConc_traits |
Attribute traits type. | |
typedef ::neuroml2::Nml2Quantity_time | decayConstant_type |
Attribute type. | |
typedef ::xsd::cxx::tree::traits< decayConstant_type, char > | decayConstant_traits |
Attribute traits type. | |
typedef ::neuroml2::Nml2Quantity_length | shellThickness_type |
Attribute type. | |
typedef ::xsd::cxx::tree::traits< shellThickness_type, char > | shellThickness_traits |
Attribute traits type. | |
![]() | |
typedef ::neuroml2::Notes | notes_type |
Element type. | |
typedef ::xsd::cxx::tree::optional< notes_type > | notes_optional |
Element optional container type. | |
typedef ::xsd::cxx::tree::traits< notes_type, char > | notes_traits |
Element traits type. | |
typedef ::neuroml2::Property | property_type |
Element type. | |
typedef ::xsd::cxx::tree::sequence< property_type > | property_sequence |
Element sequence container type. | |
typedef property_sequence::iterator | property_iterator |
Element iterator type. | |
typedef property_sequence::const_iterator | property_const_iterator |
Element constant iterator type. | |
typedef ::xsd::cxx::tree::traits< property_type, char > | property_traits |
Element traits type. | |
typedef ::neuroml2::Annotation | annotation_type |
Element type. | |
typedef ::xsd::cxx::tree::optional< annotation_type > | annotation_optional |
Element optional container type. | |
typedef ::xsd::cxx::tree::traits< annotation_type, char > | annotation_traits |
Element traits type. | |
typedef ::neuroml2::MetaId | metaid_type |
Attribute type. | |
typedef ::xsd::cxx::tree::optional< metaid_type > | metaid_optional |
Attribute optional container type. | |
typedef ::xsd::cxx::tree::traits< metaid_type, char > | metaid_traits |
Attribute traits type. | |
![]() | |
typedef ::neuroml2::NmlId | id_type |
Attribute type. | |
typedef ::xsd::cxx::tree::traits< id_type, char > | id_traits |
Attribute traits type. | |
![]() | |
const ion_type & | ion () const |
Return a read-only (constant) reference to the attribute. More... | |
ion_type & | ion () |
Return a read-write reference to the attribute. More... | |
void | ion (const ion_type &x) |
Set the attribute value. More... | |
void | ion (::std::unique_ptr< ion_type > p) |
Set the attribute value without copying. More... | |
const restingConc_type & | restingConc () const |
Return a read-only (constant) reference to the attribute. More... | |
restingConc_type & | restingConc () |
Return a read-write reference to the attribute. More... | |
void | restingConc (const restingConc_type &x) |
Set the attribute value. More... | |
void | restingConc (::std::unique_ptr< restingConc_type > p) |
Set the attribute value without copying. More... | |
const decayConstant_type & | decayConstant () const |
Return a read-only (constant) reference to the attribute. More... | |
decayConstant_type & | decayConstant () |
Return a read-write reference to the attribute. More... | |
void | decayConstant (const decayConstant_type &x) |
Set the attribute value. More... | |
void | decayConstant (::std::unique_ptr< decayConstant_type > p) |
Set the attribute value without copying. More... | |
const shellThickness_type & | shellThickness () const |
Return a read-only (constant) reference to the attribute. More... | |
shellThickness_type & | shellThickness () |
Return a read-write reference to the attribute. More... | |
void | shellThickness (const shellThickness_type &x) |
Set the attribute value. More... | |
void | shellThickness (::std::unique_ptr< shellThickness_type > p) |
Set the attribute value without copying. More... | |
DecayingPoolConcentrationModel (const id_type &, const ion_type &, const restingConc_type &, const decayConstant_type &, const shellThickness_type &) | |
Create an instance from the ultimate base and initializers for required elements and attributes. | |
DecayingPoolConcentrationModel (const ::xercesc::DOMElement &e, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a DOM element. More... | |
DecayingPoolConcentrationModel (const DecayingPoolConcentrationModel &x, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Copy constructor. More... | |
DecayingPoolConcentrationModel & | operator= (const DecayingPoolConcentrationModel &x) |
Copy assignment operator. More... | |
virtual | ~DecayingPoolConcentrationModel () |
Destructor. | |
![]() | |
const notes_optional & | notes () const |
Return a read-only (constant) reference to the element container. More... | |
notes_optional & | notes () |
Return a read-write reference to the element container. More... | |
void | notes (const notes_type &x) |
Set the element value. More... | |
void | notes (const notes_optional &x) |
Set the element value. More... | |
void | notes (::std::unique_ptr< notes_type > p) |
Set the element value without copying. More... | |
const property_sequence & | property () const |
Return a read-only (constant) reference to the element sequence. More... | |
property_sequence & | property () |
Return a read-write reference to the element sequence. More... | |
void | property (const property_sequence &s) |
Copy elements from a given sequence. More... | |
const annotation_optional & | annotation () const |
Return a read-only (constant) reference to the element container. More... | |
annotation_optional & | annotation () |
Return a read-write reference to the element container. More... | |
void | annotation (const annotation_type &x) |
Set the element value. More... | |
void | annotation (const annotation_optional &x) |
Set the element value. More... | |
void | annotation (::std::unique_ptr< annotation_type > p) |
Set the element value without copying. More... | |
const metaid_optional & | metaid () const |
Return a read-only (constant) reference to the attribute container. More... | |
metaid_optional & | metaid () |
Return a read-write reference to the attribute container. More... | |
void | metaid (const metaid_type &x) |
Set the attribute value. More... | |
void | metaid (const metaid_optional &x) |
Set the attribute value. More... | |
void | metaid (::std::unique_ptr< metaid_type > p) |
Set the attribute value without copying. More... | |
Standalone (const id_type &) | |
Create an instance from the ultimate base and initializers for required elements and attributes. | |
Standalone (const ::xercesc::DOMElement &e, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a DOM element. More... | |
Standalone (const Standalone &x, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Copy constructor. More... | |
Standalone & | operator= (const Standalone &x) |
Copy assignment operator. More... | |
virtual | ~Standalone () |
Destructor. | |
![]() | |
const id_type & | id () const |
Return a read-only (constant) reference to the attribute. More... | |
id_type & | id () |
Return a read-write reference to the attribute. More... | |
void | id (const id_type &x) |
Set the attribute value. More... | |
void | id (::std::unique_ptr< id_type > p) |
Set the attribute value without copying. More... | |
Base (const id_type &) | |
Create an instance from the ultimate base and initializers for required elements and attributes. | |
Base (const ::xercesc::DOMElement &e, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a DOM element. More... | |
Base (const Base &x, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Copy constructor. More... | |
Base & | operator= (const Base &x) |
Copy assignment operator. More... | |
virtual | ~Base () |
Destructor. | |
![]() | |
BaseWithoutId () | |
Create an instance from the ultimate base and initializers for required elements and attributes. | |
BaseWithoutId (const ::xercesc::DOMElement &e, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a DOM element. More... | |
BaseWithoutId (const ::xercesc::DOMAttr &a, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a DOM attribute. More... | |
BaseWithoutId (const ::std::string &s, const ::xercesc::DOMElement *e, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Create an instance from a string fragment. More... | |
BaseWithoutId (const BaseWithoutId &x, ::xml_schema::flags f=0, ::xml_schema::container *c=0) | |
Copy constructor. More... | |
virtual | ~BaseWithoutId () |
Destructor. | |
Class corresponding to the ConcentrationModel_D schema type.
Definition at line 49455 of file NeuroML_v2.3.hxx.
neuroml2::ConcentrationModel_D::ConcentrationModel_D | ( | const ::xercesc::DOMElement & | e, |
::xml_schema::flags | f = 0 , |
||
::xml_schema::container * | c = 0 |
||
) |
Create an instance from a DOM element.
e | A DOM element to extract the data from. |
f | Flags to create the new instance with. |
c | A pointer to the object that will contain the new instance. |
Definition at line 39450 of file NeuroML_v2.3.cxx.
neuroml2::ConcentrationModel_D::ConcentrationModel_D | ( | const ConcentrationModel_D & | x, |
::xml_schema::flags | f = 0 , |
||
::xml_schema::container * | c = 0 |
||
) |
Copy constructor.
x | An instance to make a copy of. |
f | Flags to create the copy with. |
c | A pointer to the object that will contain the copy. |
For polymorphic object models use the _clone
function instead.
Definition at line 39441 of file NeuroML_v2.3.cxx.
|
virtual |
Copy the instance polymorphically.
f | Flags to create the copy with. |
c | A pointer to the object that will contain the copy. |
This function ensures that the dynamic type of the instance is used for copying and should be used for polymorphic object models instead of the copy constructor.
Reimplemented from neuroml2::DecayingPoolConcentrationModel.
Definition at line 39491 of file NeuroML_v2.3.cxx.
ConcentrationModel_D & neuroml2::ConcentrationModel_D::operator= | ( | const ConcentrationModel_D & | x | ) |
Copy assignment operator.
x | An instance to make a copy of. |
For polymorphic object models use the _clone
function instead.
Definition at line 39498 of file NeuroML_v2.3.cxx.
const ConcentrationModel_D::type_type & neuroml2::ConcentrationModel_D::type | ( | ) | const |
Return a read-only (constant) reference to the attribute.
Definition at line 12310 of file NeuroML_v2.3.cxx.
|
static |
Return the default value for the attribute.
Definition at line 12316 of file NeuroML_v2.3.cxx.
